Neousys NRU series features edge AI computers powered by NVIDIA’s Jetson AGX Xavier™ and Jetson Xavier™ NX that offer significant inference performance while consuming only 15 to 30W of power. Benefitting from Neousys' effective thermal design, the NRU Series is truly fanless and wide-temperature operation capable. The NRU can be installed with a damping bracket, has ignition power control and accepts wide-range voltage power input, making it suitable for various mobile deployments and edge AI applications.
Furthermore, the NRU series supports a variety of cameras, such as IP, GigE and GMSL cameras. It also has a wealth of interfaces that can connect to various sensors to fulfill perception and planning functionalities on the same platform, ideal for AI-based vision applications that require continuous interactions with surroundings, such as UGV/ AMR, predictive maintenance, law enforcement, intelligent V2X, etc.
NRU Series Core Features
30W Fanless Edge AI Computer
Benefitting from the design of NVIDIA® Jetson AGX Xavier™, NRU Series has GPU computing power equivalent to 120W graphic cards while consuming only 30W of power.
Robust and Reliable
With an exclusive mechanical and efficient thermal design, the NRU series can operate from -25°C to 70°C temperatures. Moreover, it has a patented dampening bracket that can counteract shock and vibration in harsh environments.
Camera Support
NRU series supports IP, GigE and GMSL cameras to suit various edge computing image analysis applications, such as visual defect detection, security monitoring, autonomous machines, etc.
Ready for Mobile/ In-vehicle Applications
NRU Series features various in-vehicle functions such as ignition control, CAN bus, DIO and one mini-PCIe socket for WiFi/ 4G module; making the NRU series perfect for mobile or in-vehicle deployments.Neousys NRU Series Platforms:
 |
 |
 |
|
| NRU-52S | NRU-110V | NRU-120S | |
|---|---|---|---|
| Description | Rugged NVIDIA® Jetson Xavier™ NX Edge AI Computer with 4x PoE++ Ports for Intelligent Video Analytics | Edge AI platform supporting 8x GMSL automotive cameras and 10G Ethernet | AI NVR for intelligent video analytics supporting 4x PoE+ GigE camera |
| Processor | NVIDIA® Jetson Xavier™ NX system-on-module (SOM), comprising NVIDIA® Volta GPU and Carmel CPU | Supporting NVIDIA® Jetson AGX Xavier™ system-on-module, comprising of NVIDIA® Volta GPU and Carmel CPU | |
| Memory | 8GB LPDDR4x @ 1600 MHz on SOM (15W TDP mode) 8GB LPDDR4x @ 1866 MHz on SOM (20W TDP mode) |
On board 32GB LPDDR4x @ 2133 MHz on SOM | |
| eMMC | 32GB eMMC 5.1 on SOM | ||
| PoE+ | - | 4x IEEE 802.3at (25.5W) Gigabit PoE+ ports | |
| PoE++ | 4x IEEE 802.3bt PoE++ GbE ports with screw-lock | - | |
| GMSL | - | 8x GMSL cameras via FAKRA Z connector | - |
| Ethernet | 4x Gigabit ports with screw-lock, share 1 Gbps total bandwidth | 1x 10GBASE-T 10G Ethernet port | - |
| USB | 2x USB 3.1 Gen1 ports (total 5 Gbps shared with M.2 B key) | 3x USB 3.1 Gen1 (5 Gbps) ports | |
| Video Port | 2x DisplayPort, supporting 3840x2160 at 60Hz | 2x DisplayPort, supporting 3840x2160 at 60Hz | |
| Serial Port | 1x hardware configurable RS-232/422/485 port | 1x RS-232 port with flow control | |
 |
|
|
|
Applications
Intelligent Video Analytics
The NRU series can be used as a one-stop AI NVR (Network Video Recorder) solution. Through the deep learning neural network of the GPU computer to achieve the analytic results with detecting, identifying, and finding objects in an image, e.g., law enforcement, security alert, dangerous object detection, etc.
Autonomous Vehicle
The NRU series is a low-power consuming Edge AI platform suitable for outdoor robots regardless of environmental conditions, such as lighting, temperature, vibration, etc. It can be deployed in various vehicles and applied for edge AI applications, such as last-mile delivery, smart agriculture, autonomous shuttle, etc.
